Pieejams 222/600- MB ar izmēru 600x1090x280 mm — sfērisks rullīšu gultnis
Pārskats
Misiņa būris; Urbuma diametrs {{0}} mm; Ārējais diametrs-1090 mm;Platums-280 mm; Masa-1170 kg;Cr=9650 kN;C0r=17600 kN;Ierobežojošais ātrums=480 min–1
specifikācija
| Izmēri un tehniskie dati | |
| Daļas NR. | 222/600-MB — sfēriskie rullīšu gultņi |
| Zīmols | FAG zīmols ražots VĀCIJĀ |
| Galvenie izmēri | 600x1090x280 mm |
| d | 600 mm |
| D | 1090 mm |
| B | 280 mm |
| rmin. | 9,5 mm |
| D1 | 947,7 mm |
| da min. | 640 mm |
| Da maks. | 1050 mm |
| ra maks. | 4 mm |
| Kr | 9650 kN |
| C0r | 17600 kN |
| M | 1170 kg |
Tas pats tips ir pieejams arī noliktavā jūsu izvēlei
| Apzīmējums | Dizains | Masa | Izmēri | ||||||
| m = kg |
d | D | B | r D₁ | ds | ns | |||
| min | 3 | ||||||||
| 239/600-BK-MB | 2 | 210 | 600 | 800 | 150 | 5 | 7,405 | 125 | 235 |
| 239/600-B-MB | 2 | 224 | 600 | 800 | 150 | 5 | 7,405 | 125 | 235 |
| Z-528744.PRL | 2 | 281 | 600 | 800 | 200 | 5 | 7,361 | 95 | 177 |
| Z-541824.249/600-B | 3 | 294 | 600 | 800 | 200 | 5 | 7,361 | 95 | 177 |
| 249/600-K30- MB | 2 | 293 | 600 | 800 | 200 | 5 | 7,361 | 95 | 177 |
| 249/600-MB | 2 | 293 | 600 | 800 | 200 | 5 | 7,361 | 95 | 177 |
| 230/600-BK-MB | 2 | 388 | 600 | 870 | 200 | 6 | 7,919 | 125 | 235 |
| 230/600-B-MB | 2 | 409 | 600 | 870 | 200 | 6 | 7,919 | 125 | 235 |
| 240/600-BK30- MB | 2 | 544 | 600 | 870 | 272 | 6 | 7,733 | 125 | 235 |
| 240/600-B-MB | 2 | 553 | 600 | 870 | 272 | 6 | 7,733 | 125 | 235 |
| 231/600-K-MB | 2 | 901 | 600 | 980 | 300 | 75 | 8,526 | 125 | 235 |
| 231/600-MB | 2 | 929 | 600 | 980 | 300 | 75 | 8,526 | 125 | 235 |
| 241/600-BK30-MB | 2 | 1170 | 600 | 980 | 375 | 75 | 833 | 125 | 235 |
| 241/600-B-MB | 2 | 1180 | 600 | 980 | 375 | 75 | 833 | 125 | 235 |
| 222/600-MB | 2 | 1170 | 600 | 1090 | 280 | 95 | 9,477 | 125 | 235 |
| 232/600-BK-MB | 2 | 1560 | 600 | 1090 | 388 | 95 | 9,195 | 125 | 235 |
| 232/600-B-MB | 2 | 1600 | 600 | 1090 | 388 | 95 | 9,195 | 125 | 235 |
| 223/600-B-MB | 2 | 2.060 | 600 | 1220 | 355 | 15 | 10,361 | 125 | 235 |
| 223/600-MB | 2 | 2.200 | 600 | 1220 | 355 | 15 | 10,361 | 125 | 235 |
| 238/630-MB | 2 | 122 | 630 | 780 | 112 | 4 | 7,368 | 8 | 15 |
| 238/630-K-MB | 2 | 122 | 630 | 780 | 112 | 4 | 7,368 | 8 | 15 |
| 239/630-BK-MB | 2 | 283 | 630 | 850 | 165 | 6 | 7,845 | 125 | 235 |
| 239/630-B-MB | 2 | 292 | 630 | 850 | 165 | 6 | 7,845 | 125 | 235 |
| 249/630-K30- MB | 2 | 363 | 630 | 850 | 218 | 6 | 7,802 | 95 | 177 |
| 249/630-MB | 2 | 363 | 630 | 850 | 218 | 6 | 7,802 | 95 | 177 |
| Z-541825.249/630 | 3 | 375 | 630 | 850 | 218 | 6 | 7,802 | 95 | 177 |
| 230/630-BK-MB | 2 | 480 | 630 | 920 | 212 | 75 | 8,343 | 125 | 235 |
| 230/630-B-MB | 2 | 495 | 630 | 920 | 212 | 75 | 8,343 | 125 | 235 |
| 240/630-BK30- MB | 2 | 649 | 630 | 920 | 290 | 75 | 8,179 | 125 | 235 |
| 240/630-B-MB | 2 | 660 | 630 | 920 | 290 | 75 | 8,179 | 125 | 235 |
| 231/630-BK-MB | 2 | 1040 | 630 | 1030 | 315 | 75 | 8,962 | 125 | 235 |
| 231/630-B-MB | 2 | 1070 | 630 | 1030 | 315 | 75 | 8,962 | 125 | 235 |
| 241/630-BK30-MB | 2 | 1360 | 630 | 1030 | 400 | 75 | 8,722 | 125 | 235 |
| 241/630-B-MB | 2 | 1390 | 630 | 1030 | 400 | 75 | 8,722 | 125 | 235 |
